Precision laser cutting

Welcome to BBW Lasertechnik, your reliable partner for laser fine cutting and many other laser related services!

Our state of the art machinery includes 6 systems that have been specifically developed for the manufacture of high precision products. We use pulsed and continuous wave lasers, solid state lasers (rod and fibre) and ultrashort pulse lasers, both as single and multimode sources. With a traverse path of up to 2700mm x 350mm x 300mm, we offer a wide range of options for your laser fineblanking applications.

What is precision laser cutting?

In laser cutting, complex and intricate cuts are produced by focusing a very small laser beam on the material. The material melts or vaporizes at the processing point. Due to the small beam diameter, the surrounding material is not damaged, and nearly distortion-free processing is possible. Cut starts can be reduced to an imperceptible level.

Precision laser cutting is the ideal application when high repeatability is required, achieved through tight tolerance ranges in terms of dimensional accuracy, cleanliness, and cut edge geometry.

The specially developed precision laser machines are used at BBW-Lasertechnik for the production of complex geometries and very small structures with the highest accuracy. Our process is suitable for a wide variety of materials, including metals, plastics, ceramics, and many more.

The Advantages of Precision Laser Cutting

Precision laser cutting offers numerous advantages over traditional cutting methods, particularly in terms of precision, speed, and material preservation. Here are some of the key benefits:

Highest Precision and Quality
Precision laser cutting enables extremely fine cuts that surpass conventional cutting methods. With minimal cutting widths and extremely tight tolerances, we ensure that your components are manufactured exactly to your specifications. This makes the process particularly suitable for the production of components with complex geometries and tight dimensional tolerances.
Clean Cutting Edges without Post-Processing
Another advantage of precision laser cutting is the quality of the cutting edges. Since the material is processed without mechanical stress, clean and smooth edges are produced, which in many cases require no further post-processing. This saves time and costs in production, increasing overall efficiency.
Versatility in Material Selection
Precision laser cutting is suitable for a wide range of materials. Whether it's metals like stainless steel, aluminum, and copper, or plastics or delicate materials such as ceramics, our laser systems offer the flexibility to cut various materials with the highest precision. This versatility makes the process attractive to numerous industries, including medical technology, electronics, aerospace, and automotive.
Non-Contact and Material-Preserving Process
As precision laser cutting is a non-contact process, tool wear is eliminated, and the material is preserved. This is particularly important for sensitive or very thin materials that can be easily damaged by mechanical methods. The minimal thermal loads also reduce the risk of deformation or changes in material properties.
High Efficiency and Cost-Effectiveness
By enabling the fast and precise cutting of complex contours, precision laser cutting allows for efficient series production. The automation of the process reduces production times and costs, while the high accuracy of the laser minimizes scrap rates. This makes the process especially economical, particularly for larger quantities or complex components.

BBW Lasertechnik as Your Service Provider for Precision Laser Cutting

We are your partner for high-precision laser processing, offering customized solutions for a wide range of industries. Our extensive expertise and innovative technology enable us to deliver top-tier results in various application areas. Here are some of the industries where we operate as a contract manufacturer in the field of precision laser cutting:

Aerospace

In the aerospace industry, precision and reliability are essential. Our laser processing technologies provide exact cuts and highly precise machining of components used in aviation and space applications. We ensure that every component meets the stringent safety and performance requirements of this industry.

Medical Technology

Medical technology demands extremely precise and clean processing, especially for surgical instruments and implants. With our advanced laser systems and expertise, we ensure the highest quality and accuracy in the production of medical components.

Manufacturing of Housing Components for Lithium-Ion Batteries

In the production of metallic housing components for lithium-ion batteries, fine cuts and precise machining are essential to ensure battery performance and safety. Our laser technology allows us to manufacture housing components that meet the stringent requirements of this technology.

Semiconductor Industry

The semiconductor industry requires precise processing and fine structures for the production of microelectronics and other components. With our comprehensive precision laser cutting techniques, we can manufacture highly sensitive semiconductor elements with minimal tolerances and the highest quality.

Food Industry

We are also active in the food industry with our laser technology. Whether it's for processing tools used in food production or for specific cutting and structuring processes, we offer customized solutions for any requirements in the food sector.

Our Specialties in Precision Laser Cutting

In addition to processing materials for various industries, we also offer a wide range of specialized services:

Surface Structuring:
With our modern equipment, we can create precise surface structures optimized for specific requirements.
Defined Volume Removal:
Using defined volume removal, we can selectively remove material and create complex geometries with high precision.
Edge Finishing through Vibratory Grinding:
With vibratory grinding, we ensure smooth and precise cutting edges, providing an optimal finish.
Chemical Pickling:
We also offer chemical pickling to refine and clean workpieces, ensuring perfect surface quality.
Manual Reworking and Mechanical Processing:
In addition to laser processing, we perform manual reworking and mechanical processing to ensure that all components meet the highest quality standards.

Our Strengths

At BBW Lasertechnik, we are experts in precision laser cutting, providing high-precision solutions for processing thin sheets and films starting from a thickness of just 0.01 mm. Thanks to our specially developed laser cutting systems, we can realize the finest structures with the highest accuracy. At BBW, we guarantee not only exceptional precision but also maximum flexibility to meet the individual requirements of our customers.

UKP-Technologie für kalten Volumenabtrag - Laserfeinschneiden

UKP Technology for Cold Volume Removal

Our strength lies particularly in the use of Ultrashort Pulse Laser (UKP) technology, which enables us to achieve a process known as "cold volume removal." This advanced technology minimizes the thermal stress on the material, which is crucial for processing sensitive and demanding materials. We achieve tolerances of less than 5 µm with this cold removal method, avoiding any heat generation that could lead to material deformation and ensuring extremely clean and precise cuts.

Versatile Processing of Demanding Materials

BBW Lasertechnik is known for processing demanding materials. Whether it’s stainless steel, titanium, aluminum, or special alloys, we have the expertise and technology to cut even challenging materials with the highest precision. Our processes are ideally suited for applications where traditional cutting techniques reach their limits, such as in medical technology, aerospace, or the electronics industry.

Vielseitige Bearbeitung anspruchsvoller Materialien - Laserfeinschneiden

Feinrohrbearbeitung und filigrane Konturen - Laserfeinschneiden

Precision Tube Processing and Delicate Contours

Our expertise also extends to precision tube processing and cutting delicate contours. With precision laser cutting, we are capable of machining thin-walled tubes and complex geometries with minimal tolerances. This is especially important for applications where the finest cutting edges are required, such as in micromechanics or medical devices.

3D Laser Cutting and 3D Volume Removal

Another strength of BBW Lasertechnik is 3D laser cutting and 3D volume removal. With our advanced laser systems, we can cut three-dimensional shapes and structures from a variety of materials. This technology allows us to manufacture complex components and prototypes that are essential in industries such as automotive, aerospace, and mechanical engineering. Through 3D volume removal, we can precisely and efficiently remove material to create complex geometries and depth structures.

BBW Lasertechnik technische Details 3D Laserschneiden Feinrohrbearbeitung kleiner Bauteile

BBW Lasertechnik technische Details 3D Laserschneiden Feinrohrbearbeitung Laserprodukt

Manufacturing of Individual Parts for Assemblies

We understand the importance of precisely fitting individual parts for assemblies. With precision laser cutting, we are well-equipped for the production of such components. Whether it's small series or larger production runs, we deliver parts that meet the highest quality standards and can be perfectly integrated into your assemblies.

Why BBW Lasertechnik is the Right Partner?

We are your ideal partner for precision laser cutting, as we have a state-of-the-art machine park specifically designed for high-precision cuts. Our advanced laser systems—including pulse, continuous wave, and ultrashort pulse lasers—enable precise processing even for complex geometries and delicate structures. Thanks to our technology, we achieve clean cutting edges without the need for post-processing, saving time and costs. Our methods are versatile and suitable for a wide range of materials, including metals, plastics, and ceramics.

Trust us and our expertise for precise, efficient, and cost-effective solutions.

Application Examples of Precision Laser Cutting

Material Diversity in Precision Laser Cutting: Precision for Various Materials at BBW Lasertechnik

Supported Materials and Material Thicknesses

Thanks to our advanced precision laser cutting techniques and the use of state-of-the-art ultrashort pulse laser (UKP) technology, we offer our customers maximum flexibility in material selection. Our laser systems are designed to cut extremely thin and delicate materials precisely without affecting their properties.

Stainless Steels from 10 µm

For applications that require it, we can cut stainless steels starting from a thickness of just 10 µm. This capability is particularly important in medical technology, microelectronics, and other high-tech industries where precise cutting edges and minimal tolerances are crucial.

Aluminum from 10 µm

Our precision laser cutting technology enables us to cut aluminum from 10 µm. Aluminum is a material frequently used in aerospace, automotive, and electronics. We ensure that each part is manufactured with the highest accuracy.

Steels from 10 µm

We also offer precise cutting solutions for steels starting from 10 µm. Whether for machinery components, tools, or structural parts, our laser technology guarantees clean and dimensionally accurate cuts that can be directly processed or assembled.

Copper from 10 µm

Copper is well known for its excellent electrical and thermal properties and can be cut starting from a thickness of 10 µm. This capability is essential for applications in electronics and electrical engineering.

Ceramics from 10 µm

For demanding applications involving ceramics, we provide precision laser cutting starting from 10 µm. Ceramics are often used in high-temperature applications, medical technology, and the semiconductor industry. We achieve the highest cutting quality even with this brittle material.

...and much more thanks to UKP Processing

UKP technology allows us to cut a wide variety of additional materials with the highest precision, regardless of their thickness or sensitivity. This flexibility enables us to meet individual customer requirements and provide tailored solutions for a diverse range of industries.
